Auxiliary Equipment

Briquette Machine

charcoal briquette machine can be used to press coal powder, iron powder, coke, mineral powder, iron ore fines, metal dust, mill scale, iron oxide skin, carbon powder, slag, gypsum, tailings, sludge, kaolin clay, activated carbon, Coke breeze and other powder and waste material .The briquette machine is widely used in refractory, power plants, metallurgy, chemicals, energy, transportation, heating, etc. industries. The final products have features of environmental friendly, easy to transport, improving the waste recycling, and good economic and social benefits

briquette machine
Briquette  machine can be used to press coal powder, iron powder, coke, mineral powder, iron ore fines, metal dust, mill scale, iron oxide skin, carbon powder, slag, gypsum, tailings, sludge, kaolin clay, activated carbon, Coke breeze and other powder and waste material .The briquette machine is widely used in refractory, power plants, metallurgy, chemicals, energy, transportation, heating, etc. industries. The final products have features of environmental friendly, easy to transport, improving the waste recycling, and good economic and social benefits.
briquette machinebriquette machine
Working Principle of briquette machine

This series of briquette machine will pass the power on to the two pressure roller through the reducer. The two sides and roll rotation, in both the rotating roll, Natural materials to enter the ball roll mode, with the roll rotation, material pressure on a small become larger, When the material to the two rollers rotating line contact point, the pressure of materials has reached the peak. Tremendous pressure in the role of line, the materials become a finished product from the powder ball.
Technical parameters of briquette machine:
Model ZQ400
Speed ratio 1:31.5
Roller size 430mm
Width 250mm
Roller leather materials 65mn quenching process
Surface hardness 56-58
Spindle speed 15-17RPM
Power 11kw
Capacity 3-5tons
Dimension 2460*1530*2030mm


Suitable raw materials:
coal powder
mineral powder
carbon black powder
Flow chart of briquette machine:
briquette machine production line
Application for Briquette Machine:
1) Crusher is used for crushing raw material into smaller size (0-5mm)
2) Mixer is usde for mixing raw material and binder evenly
3) Briquetting machine is used for making coal briquettes
 4) Dryer is used to dry coal briquettes
Final products:
final products of briquette machine
Features of coal briquette
1).High briquette ratio
2).Durable & good performance
3).Easy to maintenance
4).High briquette pressure
