Continuous fully automatic waste tyre pyrolysis plant

Pyrolysis plant

The increasing business of extracting fuel oil from waste tires and plastic all over the world as encouraged several companies to use pyrolysis technology to develop more advanced pyrolysis plants like continuous fully automatic waste tyre pyrolysis plant. The continuous fully automatic waste tyre pyrolysis plant is equipped with an automatic feeding system and two sealed discharging systems, which makes it easy to operate. It not only can dispose 10-100 tons of waste tyre per day, but also can work continuously for 24 hours per day without a stop.

Chat Online Leave A Message
tyre pyrolysis plant
Continuous fully automatic waste tyre pyrolysis plant
The increasing business of extracting fuel oil from waste tires and plastic all over the world as encouraged several companies to use pyrolysis technology to develop more advanced pyrolysis plants like continuous fully automatic waste tyre pyrolysis plant. The continuous fully automatic waste tyre pyrolysis plant is equipped with an automatic feeding system and two sealed discharging systems, which makes it easy to operate. It not only can dispose 10-100 tons of waste tyre per day, but also can work continuously for 24 hours per day without a stop.
Continuous fully automatic waste tyre pyrolysis plant raw material
pyrolysis plant
Continuous fully automatic waste tyre pyrolysis plant application
1.Waste tyre/tire
2.Waste plastic
3.Waste rubber



continuous fully automatic waste tyre pyrolysis plant
Continuous fully automatic waste tyre pyrolysis plant
The whole continuous waste tyre pyrolysis plant is mainly composed of eleven parts, such as moving horizontal pyrolysis reactor, hot air circulation heating system, oil gas filter, spray cooling system, secondary fire retardant damper, strong spray dedusting system, oil gas recycling system, feeder system, discharging system, pressure and temperature multipoint monitoring system, central electric control system. Manufactured with high-quality materials and advanced technologies, the machine has the features of safety, energy saving and environmental protection.


Continuous fully automatic waste tyre pyrolysis plant technical data


Technical parameter of contnuous fully automatic waste tyre pyrolysis plant
No. Items Contents
1 Equipment type DY-1-6 DY-1-8 DY-1-10
2 Raw material Waste tyre Waste tyre Waste tyre
3 Structural form Horizontal rotation Horizontal rotation Horizontal rotation
4 24-hour Capacity 6 ton 8 ton 10 ton
5 Oil yield 2.7-3.3ton 3.6 -4.4ton 4.5 -5.5ton
6 Operating pressure Normal Normal Normal
7 Material of pyrolysis Reactor Q245R Q245R Q245R
8 Thickness of pyrolysis Reactor 16mm 16mm 16mm
9 Rotate speed of pyrolysis Reactor 0.4turn/minute 0.4turn/minute 0.4turn/minute
10 Total power 19KW 19KW 19KW
11 Mode of cooling Water cooling Water cooling Water cooling
12 Cooling area of condenser 100sqm 100sqm 100sqm
13 Kind of transmission Internal gear drive Internal gear drive Internal gear drive
14 Noise dB(A) ≤85 ≤85 ≤85
15 Size of Reactor(D×L) 2200×6000 2200×6600 2600×6600
16 Working form Intermittent operation Intermittent operation Intermittent operation
17 Delivery time 20days 20days 20days
18 Weight 27T 30T 35T

Prepared by customer about continuous fully automatic waste tyre pyrolysis plant
No. Item Consumption
1 Coal(for choice) 500kg/day
2 Wood(for choice) 800kg/day
3 Natural gas(for choice) 100-150kg/day
4 Oil(for choice) 300-350kg/day
5 Electricity 244kwh/day
6 Water(recycled) 60㎥ /month
7 Total power 19kw
8 Land area 35m*15m


Continuous fully automatic waste tyre pyrolysis plant application
waste tyre pyrolysis plant
Continuous fully automatic waste tyre pyrolysis plant application
1.The usage of final production-----Fueloil
Fuel oil from waste tyre are used in below industries
A.power plant factory
B.glass factory
C.cement factory
D.ceramic factory
E.aluminum factory
F.boiler factory
G.central heating factory
H.painting factory

The usage of final production-----Carbon black
Carbon black from waste tyre are used in below industries
A.electric cable jacketing
B.conveyor ban
C.hose and doormat
D.black nylon bag
E.rubber additive
F.automatic spare parts
G.heat isolation
H.black colorant in rubber materials
