Waste Tire Pyrolysis Plant

Waste tyre recycling process machine cost

Doing group is one the leading Waste tyre recycling process machine cost to fuel oil manufacturer and Exporter from China. Doing group is pioneer name in the field of Waste tyre recycling waste tyre recycling process plant in all over world. Doing believe in innovative technology and we apply the same concept in our aste tyre recycling process machine cost. These aste tyre recycling process machine cost can be most cost-effective in the world. Doing group waste tyre recycling process machine cost manufacturer cost can be availed at leading market price. In this plant get valuable output Fuel oil, Carbon Black, Steel Wire scrap, Gas.

waste tyre recycling machine
Waste tyre recycling process machine cost
Doing group is one the leading Waste tyre recycling process machine cost to fuel oil manufacturer and Exporter from China. Doing group is pioneer name in the field of Waste tyre recycling waste tyre recycling process plant  in all over world. Doing believe in innovative technology and we apply the same concept in our aste tyre recycling process machine cost. These aste tyre recycling process machine cost can be most cost-effective in the world. Doing group waste tyre recycling process machine cost manufacturer cost can be availed at leading market price. In this plant get valuable output Fuel oil, Carbon Black, Steel Wire scrap, Gas.
Waste tyre recycling process machine cost feature
tyre recycling process
Waste tyre recycling process machine cost
Safety:
1. Reactor with auto welding to guarantee the quality of welding seam and avoid cracking
2. Professional heating treatment and x-ray detection chamber for welding seam.
3. Vacuum system to prevent oil gas be back to reactor causing accident.
4. with temperature meter, pressure meter and safety valve.
Environment friendly:
1. Dedusting system to prevent gas and dust from coal burning
2. The exhaust gas will be recycled for heating reactor, no gas pollution
3. Well sealing on every junction parts to prevent gas leak, no smelly
Longer life:
1.Use Q245R special steel plate ,thickness 16mm. welding seam with auto welding and will get heating treatment and x-ray detection to extend the life of reactor to the most extend.
2. The life will be 6-8 years
Energy saving:
1. Well sealing for heating system, no gas leak and saving fuel


Waste tyre recycling process machine cost technical data

Technical parameter of Waste tyre recycling process machine cost
No. Items Contents
1 Equipment type DY-1-6 DY-1-8 DY-1-10
2 Raw material Waste tyre Waste tyre Waste tyre
3 Structural form Horizontal rotation Horizontal rotation Horizontal rotation
4 24-hour Capacity 6 ton 8 ton 10 ton
5 Oil yield 2.7-3.3ton 3.6 -4.4ton 4.5 -5.5ton
6 Operating pressure Normal Normal Normal
7 Material of pyrolysis Reactor Q245R Q245R Q245R
8 Thickness of pyrolysis Reactor 16mm 16mm 16mm
9 Rotate speed of pyrolysis Reactor 0.4turn/minute 0.4turn/minute 0.4turn/minute
10 Total power 19KW 19KW 19KW
11 Mode of cooling Water cooling Water cooling Water cooling
12 Cooling area of condenser 100sqm 100sqm 100sqm
13 Kind of transmission Internal gear drive Internal gear drive Internal gear drive
14 Noise dB(A) ≤85 ≤85 ≤85
15 Size of Reactor(D×L) 2200×6000 2200×6600 2600×6600
16 Working form Intermittent operation Intermittent operation Intermittent operation
17 Delivery time 20days 20days 20days
18 Weight 27T 30T 35T


Prepared by customer about  waste tyre recycling process machine cost
No. Item Consumption
1 Coal(for choice) 500kg/day
2 Wood(for choice) 800kg/day
3 Natural gas(for choice) 100-150kg/day
4 Oil(for choice) 300-350kg/day
5 Electricity 244kwh/day
6 Water(recycled) 60㎥ /month
7 Total power 19kw
8 Land area 35m*15m



Waste tyre recycling process machine cost final product applicaiton

Fuel oil  (40 to 45%)
tyre recycling process
Fuel oil application
The main oil product produced by our waste recycling application is the fuel oil that is wide used for industrial and commercial purposes. The oil has 40%-45% of the amount of recycled scrap tyres, which will be carried with licensed tanker trucks.


Carbon Black (30 to 35%) Carbon Black is the main product recycled by pyrolysis technology. The amount of recycled carbon black is 35%-42% (depending on the type of raw material ) of the total amount of scrap tyres recycled in the system. Carbon black is used as raw material or main ingredient in many industries and the chemical structure of carbon black strengthens, lengthens the endurance, and improves the coloring features of the materials. Carbon black produced by waste to energy pyrolysis application (CBp) is more economical compared to carbon black produced primarily from petroleum and is more price-efficient to be used as an ingredient in the industries listed
tyre recycling process cost
Carbon black application



    Electric cable jacketing
    Conveyor band
    Carrier Bands
    Hose and doormat
    Black nylon bag
    Rubber additive

    Automotive spare parts
    Heat isolation
    Black colorant in rubber materials
    Plastic pipe
    Industrial rubber products
    Fire fighting
Steel wire (10 to 15%)
Tyres contain steel wires and the amount ranges from 10% 15% of the total tyre weight. All of the steel present in the tyre can be
detached after the pyrolysis recycling process is completed.Valuable steel wires are pressed and sold to steel and scrap dealers.
